Processore Di Segnale Dbx 266xs

119,00 €
- Consegna prevista in 24/48 ore lavorative
L'aggiunta di un DBX266XS Compressor / Limiter / Gate al tuo suono dal vivo o in studio ti permette avere più controllo della dinamica per creare un suono più pulito e professionale. Avere un compressore nella vostra catena audio dà la possibilità di appianare livelli disomogenei, aggiungere sustain alle chitarre e dare un suono più profondo alla tua batteria. Inoltre aggiunge una maggiore chiarezza alle voci facendole risaltare rispetto agli strumenti circostanti. Specifiche tecniche INPUTS •Connector: 1/4" TRS, female XLR (pin 2 hot) •Type: Electronically balanced/unbalanced, RF filtered •Impedance: 40kO balanced, 20kO unbalanced •Maximum Level: >+22dBu Balanced or Unbalanced OUTPUTS •Connector: 1/4" TRS, female XLR (pin 2 hot) •Type: Impedance-balanced/unbalanced, RF filtered •Impedance (+4dBu): 100O balanced, 50O unbalanced •Impedance (-10dBu): 1kO balanced, 500O unbalanced •Maximum Level: >+21dBu balanced/unbalanced into 2kO or greater; >+18dBm balanced/unbalanced (into 600O) SIDECHAIN INSERT •Connector: 1/4" TRS Phone, Normalled: Ring = Output (send); Tip = Input (return) •Impedance: Tip = >10kO (Input), Ring = 2kO (Output) •Maximum Level: Tip = >+22dBu (Input), Ring = >+20dBu (Output) COMPRESSION •Threshold Range: -40dBu to +20dBu •Threshold Characteristic: Selectable OverEasy® or hard knee •Compression Ratio: 1:1 to Infinity:1 •Attack Time: Scalable Program-Dependent AutoDynamic™ •Release Time: Scalable Program-Dependent AutoDynamic™ EXPANDER/GATE •Threshold Range: -60dBu to +15dBu •Expansion Ratio: 1:1 to 4:1 •Attack Time: <100µSec •Release Time: Program-Dependent SYSTEM •Bandwidth: 0.35Hz - 90kHz, +0/-3dB •Frequency Response (Flat): 20Hz - 20kHz; +0/-0.5dB, •Noise: <-93dBu, unweighted (22kHz measurement bandwidth) •THD + N: <0.2%; Any Amount of Compression @1kHz •Intermodulation Distortion: <0.2% SMPTE •Dynamic Range: >114dB, unweighted •Interchannel Crosstalk <-95dB, 20Hz to 20kHz •CMRR: >40dB, typically >55dB at 1kHz •Stereo Coupling: True RMS Power Summing™ POWER •Power Consumption: 15 Watts Maximum •Operating Voltage: 100 VAC 50/60Hz; 120VAC 60Hz; 230 VAC 50/60 Hz •Operating Temperature: 0°C to 45°C (32°F to 113°F) PHYSICAL •Dimensions: 1.75" x 5.75" x 19" (4.45 cm x 14.6 cm x 48.26 cm ) •Weight: Net weight: 4.84 lbs (2.19 kg) •Shipping weight: 6.6 lbs (2.99 kg) •Note*: 0dBu = 0.775Vrms
DBX
07026141
Disponibile
